Mechanism:
Gives compactibility directly in percentage. Also can make a standard specimen for further tests. Accessories; Compactbility tube, specimen tube, a cup, Stripper. Needs compressed air @ 4Kg/cm sq. Higher pressures can be regulated on the FRL unit on the equipment
Misc Spec.:
Pneumatically actuated with settable pneumatic pressure to meet foundry specific simulation requirements.
Sand Type: Green Sand
Test:..
Application:
Gives compactibility directly in percentage. Also can make a standard specimen for further tests.
| Specifications | |
| Width: | 275 |
| Depth: | 120 |
| Height: | 600 |
| Weight: | 40 |
| Utility: | .. |
| Range: | For Squeezer – One Specimen For Compactibilty – 0 to 70 % |
Precautions:
Clean the equipment after use. Protect the specimen tube from rusting; apply rust preventing oil when not in use. Take care of Hands. Do not insert under the plunger. Use dry air to get long life of cylinder. Remove the water collected in filter time to time.
Maintainance:
..
Testing Prcoedure:
Please contact us for test procedure.
Optional Models: Sand Rammer with Base Block (VR+VRB) along with Compactibility tester (VCT)
Pre-Requisite Equipments: NA
